AMSRD-5SNZ - aimtec

AMSRD-5SNZ Details

• Manufacturer Part Number:

  AMSRD-5SNZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN-6

• ECCN Code:

  EAR99

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Aimtec

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  EN, IEC, UL

• Efficiency (Main Output):

  91%

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  6.5 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-PDSO-N6

• Length:

  9 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.4%

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  6

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.5 A

• Output Voltage-Max:

  5.25 V

• Output Voltage-Min:

  4.5 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SON

• Package Equivalence Code:

  SOLCC6,.27,100

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.015907 Vrms

• Screening Level:

  EN 62368

• Seated Height-Max:

  3.35 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  2.5 W

• Trim/Adjustable Output:

  YES

• Width:

  7 mm
