AOC2012VAJC-25.0000C - ABRACON

AOC2012VAJC-25.0000C Frequently Asked Questions (FAQs)

• What is the recommended termination resistance for this oscillator?
  The recommended termination resistance for the AOC2012VAJC-25.0000C is 1 kΩ to ensure proper signal integrity and minimize reflections.
• Can I use this oscillator in a harsh environment with high temperatures?
  The AOC2012VAJC-25.0000C is rated for operation from -40°C to +85°C, but it's recommended to derate the frequency stability and consider additional thermal management for extreme temperature applications.
• How do I ensure the oscillator's output is properly decoupled from the power supply?
  Use a 0.01 μF to 0.1 μF decoupling capacitor between the VDD pin and GND, and a 10 μF to 22 μF bulk capacitor between the power supply and GND to ensure proper decoupling and noise reduction.
• What is the typical start-up time for this oscillator?
  The typical start-up time for the AOC2012VAJC-25.0000C is around 5 ms to 10 ms, but this can vary depending on the specific application and power supply conditions.
• Can I use this oscillator in a design with multiple power domains?
  Yes, the AOC2012VAJC-25.0000C can be used in designs with multiple power domains, but ensure that the oscillator's power supply is properly isolated and decoupled from other power domains to prevent noise coupling and interference.
