AOC2522BVAUC-20.0000 - ABRACON

AOC2522BVAUC-20.0000 Details

• Manufacturer Part Number:

  AOC2522BVAUC-20.0000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  Abracon Corporation

• YTEOL:

  9

• Aging:

  0.1 PPM/YEAR

• Control Voltage-Max:

  3.3 V

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  0.01%

• Frequency Stability-Voltage:

  0.01 ppm

• Input Power:

  1 W

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  7

• Operating Frequency-Nom:

  20 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  HCMOS

• Output Load:

  13.5 pF

• Oven Supply Voltage:

  3.3V

• Package Equivalence Code:

  DILCC7,1,350/300/200

• Packing Method:

  TRAY

• Physical Dimension:

  25.4mm x 22mm x 12mm

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Warm-up Power:

  3.2 W

• Warm-up Time-Max:

  15 Minute
