AOCJY-100.000MHZ Frequently Asked Questions (FAQs)

• What is the recommended soldering temperature profile for the AOCJY-100.000MHZ?
  Abracon recommends a soldering temperature profile with a peak temperature of 240°C to 250°C, with a dwell time of 1-2 seconds. This ensures reliable solder joints and minimizes thermal stress on the component.
• How does the AOCJY-100.000MHZ oscillator perform in high-vibration environments?
  The AOCJY-100.000MHZ is designed to operate in environments with moderate vibration levels. However, for high-vibration applications, Abracon recommends using a vibration-dampening material or a custom-designed mounting system to ensure reliable operation.
• Can the AOCJY-100.000MHZ be used in applications requiring high-temperature operation?
  While the AOCJY-100.000MHZ is rated for operation up to 85°C, Abracon recommends derating the frequency tolerance and stability specifications for operation above 70°C. For high-temperature applications, consider using Abracon's high-temperature oscillators, such as the AOCJY-HT series.
• What is the recommended PCB layout and trace routing for the AOCJY-100.000MHZ?
  Abracon recommends using a symmetrical PCB layout with a solid ground plane and 50-ohm transmission lines to minimize signal reflections and ensure optimal oscillator performance. Keep the oscillator input and output traces as short as possible and avoid routing them near noise-sensitive components.
• How does the AOCJY-100.000MHZ oscillator behave during power-up and power-down cycles?
  The AOCJY-100.000MHZ oscillator is designed to start oscillating within 10 ms of power-up and to maintain oscillation during power-down cycles. However, Abracon recommends using a power-up ramp time of at least 1 ms to ensure reliable oscillator start-up.
