AOCJY5-10.000MHZ - ABRACON

AOCJY5-10.000MHZ Details

• Manufacturer Part Number:

  AOCJY5-10.000MHZ

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  ROHS COMPLIANT PACKAGE-5

• Factory Lead Time:

  32 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  0

• Additional Feature:

  TRAY

• Aging:

  0.1 PPM/FIRST YEAR

• Control Voltage-Max:

  5 V

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  0.05%

• Frequency Stability-Voltage:

  0.001 ppm

• Input Power:

  5 W

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  5

• Offset Frequency:

  1 kHz

• Operating Frequency-Nom:

  10 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Oscillator Type:

  SINE

• Output Impedance:

  50 Ω

• Output Level:

  1.416 V

• Oven Supply Voltage:

  12V

• Package Body Material:

  METAL

• Package Equivalence Code:

  DIP5/6,1,350

• Phase Noise:

  -145 dBc/Hz

• Physical Dimension:

  36.1mm x 27.2mm x 13.0mm

• Qualification Status:

  Not Qualified

• Supply Voltage-Max:

  12.6 V

• Supply Voltage-Min:

  11.4 V

• Supply Voltage-Nom:

  12 V

• Surface Mount:

  NO

• Warm-up Power:

  6 W

• Warm-up Time-Max:

  3 Minute
