AOCJY6-10.000MHZ-5 - ABRACON

AOCJY6-10.000MHZ-5 Details

• Manufacturer Part Number:

  AOCJY6-10.000MHZ-5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  0

• Aging:

  0.02 PPM/YEAR

• Control Voltage-Max:

  6 V

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  0.0005%

• Frequency Stability-Voltage:

  0.0001 ppm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  5

• Offset Frequency:

  1 kHz

• Operating Frequency-Nom:

  10 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Oscillator Type:

  SINE

• Output Impedance:

  50 Ω

• Output Level:

  1.589 V

• Oven Supply Voltage:

  12V

• Package Equivalence Code:

  DIP5/6,1.25,826

• Packing Method:

  TRAY

• Phase Noise:

  -145 dBc/Hz

• Physical Dimension:

  51mm x 41mm x 25mm

• Supply Current-Max:

  800 mA

• Supply Voltage-Max:

  12.6 V

• Supply Voltage-Min:

  11.4 V

• Supply Voltage-Nom:

  12 V

• Surface Mount:

  NO
