AP33510S9-13 - Diodes Incorporated

AP33510S9-13 Details

• Manufacturer Part Number:

  AP33510S9-13

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  3

• Analog IC - Other Type:

  SWITCHING CONTROLLER

• Control Technique:

  PULSE FREQUENCY MODULATION

• Input Voltage-Max:

  40 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  18 V

• JESD-30 Code:

  R-PDSO-G9

• JESD-609 Code:

  e3

• Length:

  4.9 mm

• Number of Functions:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Equivalence Code:

  SSOP9,.25,40

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Seated Height-Max:

  1.75 mm

• Supply Current-Max (Isup):

  1.5 mA

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK-BOOST

• Switching Frequency-Max:

  150 kHz

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1 mm

• Terminal Position:

  DUAL

• Width:

  3.9 mm
