AP72202CT20-7 - Diodes Incorporated

AP72202CT20-7 Details

• Manufacturer Part Number:

  AP72202CT20-7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  BGA-20

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  24 Weeks

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  8

• Additional Feature:

  PULSE WIDTH MODULATION IS AVAILABLE

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  CURRENT-MODE

• Control Technique:

  PULSE FREQUENCY MODULATION

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  2.3 V

• Input Voltage-Nom:

  2.9 V

• JESD-30 Code:

  R-PBGA-B20

• Length:

  2.125 mm

• Number of Functions:

  1

• Number of Terminals:

  20

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Output Current-Max:

  2 A

• Output Voltage-Max:

  5.14 V

• Output Voltage-Min:

  2.6 V

• Output Voltage-Nom:

  3.4 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFLGA

• Package Equivalence Code:

  BGA20,4X5,16

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  0.7 mm

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK-BOOST

• Switching Frequency-Max:

  2900 kHz

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Width:

  1.75 mm
