AP7346D-3330FS6-7 - Diodes Incorporated

AP7346D-3330FS6-7 Details

• Manufacturer Part Number:

  AP7346D-3330FS6-7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  111 Weeks

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  0

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  0.29 V

• Dropout Voltage1-Nom:

  0.22 V

• Dropout Voltage2-Max:

  0.3 V

• Input Voltage-Max:

  5.25 V

• Input Voltage-Min:

  4.3 V

• JESD-30 Code:

  S-PDSO-N6

• JESD-609 Code:

  e3

• Length:

  1.2 mm

• Load Regulation-Max(%):

  0.03%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current1-Max:

  0.12 A

• Output Current2-Max:

  0.12 A

• Output Voltage1-Max:

  3.3495 V

• Output Voltage1-Min:

  3.2505 V

• Output Voltage1-Nom:

  3.3 V

• Output Voltage2-Max:

  3.045 V

• Output Voltage2-Min:

  2.955 V

• Output Voltage2-Nom:

  3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC6,.05,16

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR, 7 INCH

• Peak Reflow Temperature (Cel):

  260

• Regulator Type:

  FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  0.4 mm

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  DUAL

• Width:

  1.2 mm
