APAKN2504-S2448-T - ABRACON

APAKN2504-S2448-T Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  Abracon recommends following the recommended PCB layout guidelines in the datasheet, including using a solid ground plane, minimizing trace lengths, and using 50-ohm transmission lines for clock signals.
• How do I ensure the oscillator is properly biased?
  The APAKN2504-S2448-T requires a bias voltage of 1.8V to 3.3V. Ensure the bias voltage is within this range and that the oscillator is properly decoupled with a 0.01uF capacitor.
• What is the maximum operating temperature range for this oscillator?
  The APAKN2504-S2448-T is rated for operation from -40°C to +85°C. However, it's recommended to derate the frequency tolerance and stability over temperature according to the datasheet specifications.
• Can I use this oscillator in a high-vibration environment?
  The APAKN2504-S2448-T is designed to meet the requirements of MIL-STD-883, Method 2007.1 for vibration. However, it's recommended to consult with Abracon's application engineers to ensure the oscillator meets the specific vibration requirements of your application.
• What is the lead time and availability of this part?
  Lead time and availability may vary depending on the region and distributor. It's recommended to check with authorized distributors such as Digi-Key, Mouser, or Avnet for the latest lead time and availability information.
