APTC60DSKM70CT1G - Microsemi Corporation

APTC60DSKM70CT1G Details

• Manufacturer Part Number:

  APTC60DSKM70CT1G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT, SP1, 12 PIN

• Pin Count:

  12

• ECCN Code:

  EAR99

• Manufacturer:

  Microsemi Corporation (now Microchip)

• YTEOL:

  0

• Additional Feature:

  AVALANCHE RATED, ULTRA-LOW RESISTANCE

• Avalanche Energy Rating (Eas):

  1800 mJ

• Case Connection:

  ISOLATED

• Configuration:

  COMMON DRAIN, 2 ELEMENTS WITH BUILT-IN DIODE AND THERMISTOR

• DS Breakdown Voltage-Min:

  600 V

• Drain Current-Max (ID):

  39 A

• Drain-source On Resistance-Max:

  0.07 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  R-XUFM-X10

• Number of Elements:

  2

• Number of Terminals:

  10

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  250 W

• Pulsed Drain Current-Max (IDM):

  160 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
