ARA200A48X - Panasonic

ARA200A48X Details

• Manufacturer Part Number:

  ARA200A48X

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  8.2

• Body Breadth:

  9.7 mm

• Body Height:

  5.9 mm

• Body Length or Diameter:

  14.7 mm

• Characteristic Impedance:

  50 Ω

• Coil Current(DC)-Max:

  0.006 A

• Coil Operate Voltage(DC):

  36 V

• Coil Power:

  300 mW

• Coil Release Voltage(DC):

  4.8 V

• Coil Resistance:

  7680 Ω

• Coil Voltage(DC)-Max:

  48 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@30VDC

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  100000 Cycle(s)

• Input Power-Max:

  3 W

• Insertion Loss-Max:

  0.3 dB

• Isolation-Max:

  30 dB

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Operate Time:

  4 ms

• Operating Frequency-Max:

  1000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TAPE AND REEL

• Physical Dimension:

  14.7mm X 9.7mm X 5.9mm

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  RF RELAY

• Release Time:

  4 ms

• Surface Mount:

  NO

• Switching Time:

  4 ms

• Termination Type:

  SOLDER

• VSWR:

  1.2
