ARJ14A-MESA-MU2 - ABRACON

ARJ14A-MESA-MU2 Details

• Manufacturer Part Number:

  ARJ14A-MESA-MU2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Abracon Corporation

• Additional Feature:

  4 PORT 8 POSITION EACH

• Board Mounting Option:

  HOLE 0.126

• Body Breadth:

  0.535 inch

• Body Depth:

  0.846 inch

• Body Length:

  2.328 inch

• Body/Shell Style:

  JACK

• Connector Type:

  RJ CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  RECTANGULAR

• Contact Style:

  MAGNETIC RJ45

• Empty Shell:

  NO

• Filter Feature:

  YES

• Mixed Contacts:

  NO

• Mounting Option 1:

  MOUNTING FLANGE

• Mounting Option 2:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  2

• Number of Ports:

  4

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  70 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  2.54 mm

• Plating Thickness:

  6u inch

• Polarization Key:

  POLARIZED HOUSING

• Terminal Length:

  0.13 inch

• Terminal Pitch:

  2.54 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  32
