ARJ2012 footprint, schematic symbol and 3D model by Panasonic

Symbol

PCB Footprints

ARJ2012 Details

Panasonic recommends a 4-layer PCB with a solid ground plane on the bottom layer, and a microstrip line layout for the high-frequency signals. A minimum of 10mil clearance between the component and other copper features is also recommended.
The ARJ2012 requires a bias voltage of 5V ± 10% and a bias current of 10mA ± 10%. Ensure that the bias voltage is stable and noise-free, and that the bias current is limited to prevent overheating.
The ARJ2012 is rated for operation from -40°C to +125°C, but the maximum operating temperature range may vary depending on the specific application and environmental conditions. Consult the datasheet and Panasonic's application notes for more information.
The ARJ2012 is sensitive to electrostatic discharge (ESD). Handle the component with ESD-protective equipment, and ensure that the PCB design includes ESD protection devices such as TVS diodes or ESD-protection ICs.
Store the ARJ2012 in a dry, cool place away from direct sunlight. Handle the component with care to prevent mechanical stress, and avoid exposing it to moisture or extreme temperatures.

Manufacturer Collaborated

System Verified

Community Approved

Use the download button to access the ARJ2012 schematic symbol and PCB footprint.

To find more CAD model downloads similar to this part, try a partial part number search, like ARJ20, or try a keyword search, such as RF Relays
