AS24AH - NKK Switches

AS24AH Details

• Manufacturer Part Number:

  AS24AH

• Brand Name:

  NKK Switches

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.50

• Manufacturer:

  NKK Switches

• Actuator Color:

  WHITE

• Actuator Length:

  0.098 inch

• Actuator Material:

  GLASS FILLED POLYAMIDE

• Actuator Type:

  SLIDE

• Additional Feature:

  MOUNTING BRACKET

• Body Breadth:

  10.0076 mm

• Body Height:

  15.2146 mm

• Body Length or Diameter:

  9.8044 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  GOLD OVER SILVER

• Contact (DC) Max Power Rating R Load:

  0.4VA@28VDC

• Contact Function:

  ON-ON-ON

• Contact Resistance:

  0.05 mΩ

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  50000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  GLASS FILLED NYLON

• Insulation Resistance:

  500000000 Ω

• Insulator Material:

  CARBON COMPOSITE POLYMER

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -10 °C

• PCB Hole Count:

  8

• Solderability:

  WAVE

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP3T

• Switch Type:

  SLIDE SWITCH

• Terminal Finish:

  GOLD

• Terminal Length:

  0.142 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
