AS5147U-HTST - ams OSRAM

AS5147U-HTST Details

• Manufacturer Part Number:

  AS5147U-HTST

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  TSSOP-14

• Manufacturer:

  ams OSRAM Group

• YTEOL:

  9

• Additional Feature:

  AEC-Q100, ISO-26262-ASIL-D

• Body Breadth:

  4.4 mm

• Body Height:

  1 mm

• Body Length or Diameter:

  5 mm

• Housing:

  PLASTIC

• JESD-609 Code:

  e3

• Measurement Range-Max (deg):

  360 deg

• Mounting Feature:

  SURFACE MOUNT

• Operating Current-Max:

  16 mA

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Output Interface Type:

  SPI INTERFACE

• Output Range:

  0.40-2.80V

• Output Type:

  DIGITAL VOLTAGE

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  ROTARY POSITION SENSOR,HALL EFFECT

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3 V

• Surface Mount:

  YES

• Terminal Finish:

  TIN

• Termination Type:

  SOLDER
