AS7341-DLGT - ams OSRAM

Description: Ambient Light Sensors MULTISPECTRAL SENSOR

Download AS7341-DLGT Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AS7341-DLGT - ams OSRAM PCB footprint - Other - Other - OLGA-8
click to zoom
3D Models
AS7341-DLGT - ams OSRAM  - 3D model - Other - OLGA-8
click to zoom

AS7341-DLGT Details

  • Manufacturer Part Number:

    AS7341-DLGT

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    End Of Life

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    ams OSRAM Group

  • YTEOL:

    1

  • Body Breadth:

    2 mm

  • Body Height:

    1 mm

  • Body Length or Diameter:

    3.1 mm

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -30 °C

  • Output:

    OPEN-DRAIN

  • Output Type:

    DIGITAL VOLTAGE

  • Package Shape/Style:

    RECTANGULAR

  • Sensors/Transducers Type:

    SPECTRUM SENSOR

  • Supply Voltage-Max:

    2 V

  • Supply Voltage-Min:

    1.7 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Matte Tin (Sn)
