ASFM0125S - Panasonic

ASFM0125S Details

• Manufacturer Part Number:

  ASFM0125S

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Panasonic Electronic Components

• Body Breadth:

  14 mm

• Body Height:

  7.8 mm

• Body Length or Diameter:

  33 mm

• Coil Current(DC)-Max:

  0.023 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  270 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  533 Ω

• Coil Voltage(DC)-Max:

  14.4 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  6A@250VAC

• Contact Current(AC)-Max:

  6 A

• Contact Current(DC)-Max:

  6 A

• Contact (DC) Max Rating R Load:

  6A@30VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  Silver Tin Oxide

• End Contact Plating:

  GOLD FLASH

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  6

• Operate Time:

  15 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  33mm x 14mm x 7.8mm

• Reference Standard:

  CUL; TUV; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A,B

• Relay Function:

  DPST

• Relay Type:

  SAFETY RELAY

• Release Time:

  10 ms

• Sealing:

  RT3

• Surface Mount:

  NO

• Terminal Length:

  0.0027940055880111762 inch

• Termination Type:

  SOLDER
