ASG2-P-V-B-320.000MHZ - ABRACON

ASG2-P-V-B-320.000MHZ Details

• Manufacturer Part Number:

  ASG2-P-V-B-320.000MHZ

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 6 PIN

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  7

• Additional Feature:

  ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT; BULK

• Control Voltage-Max:

  2.5 V

• Fall Time-Max:

  0.6 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Deviation/Pullability:

  35 ppm

• Frequency Stability:

  35%

• Linearity:

  15%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  320 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVPECL

• Output Load:

  50 OHM

• Package Body Material:

  CERAMIC

• Physical Dimension:

  2.5mm x 2.0mm x 1.0mm

• Rise Time-Max:

  0.6 ns

• Supply Voltage-Max:

  2.625 V

• Supply Voltage-Min:

  2.375 V

• Supply Voltage-Nom:

  2.5 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %
