ASGTX-D-24.576MHZ-1 Frequently Asked Questions (FAQs)

• What is the recommended termination resistance for this oscillator?
  The recommended termination resistance for the ASGTX-D-24.576MHZ-1 is 1 kΩ to ensure proper signal integrity and minimize reflections.
• Can I use this oscillator in a harsh environment with high temperatures?
  The ASGTX-D-24.576MHZ-1 is rated for industrial temperature range (-40°C to 85°C), but it's not suitable for extreme temperatures. For high-temperature applications, consider Abracon's high-temperature oscillators or consult with their application engineers.
• How do I ensure the oscillator's output is properly decoupled from the power supply?
  Use a 0.01 μF to 0.1 μF decoupling capacitor between the VCC pin and GND pin, and place it as close to the oscillator as possible to minimize noise and ensure stable operation.
• What is the typical start-up time for this oscillator?
  The typical start-up time for the ASGTX-D-24.576MHZ-1 is around 5 ms, but this can vary depending on the specific application and board layout. Consult the datasheet or contact Abracon's support for more information.
• Can I use this oscillator in a design with multiple power domains?
  Yes, the ASGTX-D-24.576MHZ-1 can be used in designs with multiple power domains, but ensure that the oscillator's power supply is properly isolated and decoupled from other power domains to prevent noise and interference.
