ASGTX-P-1.500GHZ-1 - ABRACON

ASGTX-P-1.500GHZ-1 Details

• Manufacturer Part Number:

  ASGTX-P-1.500GHZ-1

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 6 PIN

• Country Of Origin:

  New Zealand

• Factory Lead Time:

  4 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6

• Additional Feature:

  COMPLEMENTARY OUTPUT

• Aging:

  1 PPM/YEAR

• Control Voltage-Max:

  3.3 V

• Fall Time-Max:

  0.35 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Deviation/Pullability:

  10 ppm

• Frequency Stability:

  1%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  1500 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -30 °C

• Oscillator Type:

  LVPECL

• Package Equivalence Code:

  DILCC6,.28,110

• Physical Dimension:

  9.0mm x 7.0mm x 2.24mm

• Rise Time-Max:

  0.35 ns

• Supply Current-Max:

  60 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %
