ASM330LHHXG1TR - STMicroelectronics

Description: Accelerometer, Gyroscope, 6 Axis Sensor I2C, I3C, SPI Output, 1.3mA, -40°C ~ 125°C

Download ASM330LHHXG1TR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
3D Models
ASM330LHHXG1TR - STMicroelectronics  - 3D model
click to zoom
Note! To download footprints and symbols, use the build and request forms below

Build

Launch Build Wizard
Build Wizard not available for this package category!

Request (48 hours)

ASM330LHHXG1TR Details

  • Manufacturer Part Number:

    ASM330LHHXG1TR

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Malta

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    20 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    12

  • Sensors/Transducers Type:

    ACCELEROMETER/GYROSCOPE

  • Technology:

    CMOS

ASM330LHHXG1TR Frequently Asked Questions (FAQs)

  • STMicroelectronics provides a recommended PCB layout in the application note AN5122, which includes guidelines for component placement, routing, and grounding to minimize noise and ensure optimal performance.
  • The ASM330LHHXXTR has a built-in self-test feature that can be used for calibration. Additionally, STMicroelectronics provides a calibration procedure in the application note AN5122, which includes steps for calibrating the accelerometer and gyroscope using the device's internal registers.
  • The ASM330LHHXTR is rated for operation from -40°C to 85°C, but it can be extended to 105°C with some limitations. Refer to the datasheet for more information on temperature range and limitations.
  • The ASM330LHHXTR has a digital interface that can be connected to a microcontroller using I2C or SPI protocols. STMicroelectronics provides example code and documentation for popular microcontrollers, such as Arduino and STM32, in the device's software development kit (SDK).
  • The power consumption of the ASM330LHHXTR depends on the operating mode and frequency. In low-power mode, the device consumes around 0.4 mA, while in high-performance mode, it consumes around 6.5 mA. Refer to the datasheet for more information on power consumption and power modes.
