ASMT-QTB4-0AA02 - Avago Technologies

Description: BROADCOM LIMITED - ASMT-QTB4-0AA02 - LED, PLCC4 RGB, BLACK SURFACE

Download ASMT-QTB4-0AA02 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ASMT-QTB4-0AA02 - Avago Technologies PCB footprint - Other - Other - ASMT-QTB4-0AA02-1
click to zoom

ASMT-QTB4-0AA02 Details

  • Manufacturer Part Number:

    ASMT-QTB4-0AA02

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    ROHS COMPLIANT, PLASTIC, SMT, LCC-4

  • Reach Compliance Code:

    Compliant

  • HTS Code:

    8541.40.20.00

  • Manufacturer:

    Avago Technologies

  • YTEOL:

    0

  • Additional Feature:

    HIGH RELIABILITY

  • Color:

    RED/GREEN/BLUE

  • Configuration:

    COMMON ANODE, 3 ELEMENTS

  • Forward Current-Max:

    0.05 A

  • Luminous Intensity-Nom:

    620.0/1200.0/280.0 mcd

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Functions:

    1

  • Number of Terminals:

    4

  • Operating Temperature-Max:

    110 °C

  • Operating Temperature-Min:

    -40 °C

  • Optoelectronic Device Type:

    TRIPLE COLOR LED

  • Overall Height:

    2 mm

  • Packing Method:

    TR, 7 INCH

  • Peak Wavelength:

    629/521/464 nm

  • Shape:

    ROUND

  • Size:

    2.9 mm

  • Surface Mount:

    YES

  • T-code:

    T-1

  • Viewing Angle:

    120 deg

ASMT-QTB4-0AA02 Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for the ASMT-QTB4-0AA02 is -40°C to 125°C.
  • To ensure reliable operation in high-temperature environments, it is recommended to follow proper thermal design and management practices, such as providing adequate heat sinking and airflow, and ensuring that the device is operated within its specified temperature range.
  • The maximum current rating for the ASMT-QTB4-0AA02 is 1.5A per channel.
  • To configure the ASMT-QTB4-0AA02 for optimal performance, follow the recommended settings and guidelines outlined in the datasheet, and consult with Broadcom Limited's application notes and technical support resources as needed.
  • Key considerations for PCB layout and design when using the ASMT-QTB4-0AA02 include providing adequate power and ground planes, minimizing signal trace lengths and impedance, and ensuring proper decoupling and filtering.
