ASP-103612-03 footprint, schematic symbol and 3D model by SAMTEC

Symbol

click to zoom

PCB Footprints

ASP-103612-03 - SAMTEC PCB footprint - Other - Other - ASP-103612-03-2

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for ASP-103612-03
Part Number ASP-103612-03
Manufacturer SAMTEC
Pin Count 114
Part Category Connector
Package Category Other
Footprint Name Other - ASP-103612-03-2
Released Date Oct 20, 2024
Last Modified Date Sep 9, 2025 9:48 AM UTC
Pinout / Pin List Click Here (Member Only)

ASP-103612-03 Details

Manufacturer Part Number:
ASP-103612-03
Part Life Cycle Code:
Active
Country Of Origin:
Malaysia, USA
ECCN Code:
EAR99
HTS Code:
8536.69.40.40
Factory Lead Time:
1 Week
Manufacturer:
Samtec Inc
YTEOL:
9.4
Body/Shell Style:
SOCKET
Connector Type:
BOARD CONNECTOR
Contact Finish Mating:
GOLD (30) OVER NICKEL (50)
Contact Gender:
FEMALE
DIN Conformance:
NO
Filter Feature:
NO
IEC Conformance:
NO
MIL Conformance:
NO
Mixed Contacts:
NO
Mounting Style:
STRAIGHT
Mounting Type:
BOARD
Number Of Connectors:
ONE
Number of Rows Loaded:
6
Option:
GENERAL PURPOSE
Terminal Pitch:
1.27 mm
Termination Type:
SURFACE MOUNT
Total Number of Contacts:
114

ASP-103612-03 Frequently Asked Questions (FAQs)

The recommended torque for the screws on the ASP-103612-03 connector is 0.5-1.5 in-lbs (0.056-0.169 Nm).
Yes, the ASP-103612-03 connector is designed to withstand high-vibration environments. It meets the IEC 61373 Category 2 vibration standard.
Yes, the ASP-103612-03 connector is compatible with lead-free soldering processes and meets the RoHS and WEEE directives.
The operating temperature range for the ASP-103612-03 connector is -55°C to 125°C (-69°F to 257°F).
The ASP-103612-03 connector is not designed for use in humid or wet environments. It is recommended to use a connector with a higher IP rating (e.g., IP67 or higher) for such applications.

Trust Checks

Manufacturer Collaborated

System Verified

Community Approved

ASP-103612-03 Overview

Use the download button to access the ASP-103612-03 schematic symbol and PCB footprint.

To find more CAD model downloads similar to this part, try a partial part number search, like ASP-1, or try a keyword search, such as Headers and Edge Type Connectors
