ASP-105885-01 footprint, schematic symbol and 3D model by SAMTEC

Symbol

click to zoom

PCB Footprints

ASP-105885-01 - SAMTEC PCB footprint - Other - Other - ASP-105885-01-3

click to zoom

3D Models

ASP-105885-01 - SAMTEC - 3D model - Other - ASP-105885-01-3

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for ASP-105885-01
Part Number ASP-105885-01
Manufacturer SAMTEC
Pin Count 114
Part Category Connector
Package Category Other
Footprint Name Other - ASP-105885-01-3
Released Date May 8, 2020
Last Modified Date Mar 7, 2023 4:10 PM UTC
Pinout / Pin List Click Here (Member Only)

ASP-105885-01 Details

Manufacturer Part Number:
ASP-105885-01
Rohs Code:
Yes
Part Life Cycle Code:
Active
Country Of Origin:
Malaysia, USA
ECCN Code:
EAR99
HTS Code:
8536.69.40.40
Factory Lead Time:
4 Weeks, 3 Days
Manufacturer:
Samtec Inc
YTEOL:
9.4
Body Breadth:
0.42 inch
Body Depth:
0.357 inch
Body Length:
1.05 inch
Connector Type:
BOARD CONNECTOR
Contact Finish Mating:
NOT SPECIFIED
Contact Gender:
MALE
Contact Pattern:
RECTANGULAR
Contact Style:
SQ PIN-SKT
DIN Conformance:
NO
Filter Feature:
NO
IEC Conformance:
NO
MIL Conformance:
NO
Mating Contact Pitch:
0.05 inch
Mixed Contacts:
NO
Mounting Style:
STRAIGHT
Mounting Type:
BOARD
Number Of Connectors:
ONE
Number Of PCB Rows:
6
Number of Rows Loaded:
6
Option:
GENERAL PURPOSE
Terminal Pitch:
1.27 mm
Termination Type:
SURFACE MOUNT
Total Number of Contacts:
114
UL Flammability Code:
94V-0

ASP-105885-01 Frequently Asked Questions (FAQs)

The recommended torque for the screws on the ASP-105885-01 is 0.5-1.5 Nm (4-12 in-lbs). However, it's essential to consult the specific screw type and material used in your application to ensure the correct torque value.
Yes, the ASP-105885-01 is designed to withstand high-vibration environments. Samtec's ASP series is known for its ruggedness and can operate in environments with vibrations up to 20 G's.
The ASP-105885-01 has an operating temperature range of -55°C to 125°C (-133°F to 257°F). However, it's essential to note that the temperature range may vary depending on the specific application and environmental conditions.
Yes, the ASP-105885-01 is compatible with lead-free soldering processes. Samtec's ASP series is designed to meet the requirements of lead-free soldering, making it suitable for RoHS-compliant applications.
The ASP-105885-01 has a mating cycle life of 500 cycles minimum. However, the actual mating cycle life may vary depending on the specific application, usage, and environmental conditions.

Trust Checks

Expert Contribution

System Verified

Community Approved

ASP-105885-01 Overview

Use the download button to access the ASP-105885-01 schematic symbol, PCB footprint, and 3D model.
