AT42QT2120-MMHR - Microchip

Description: Capacitive Touch Sensors QTouchADC, 12 Button Wheel/Slider

Download AT42QT2120-MMHR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
AT42QT2120-MMHR - Microchip - PCB symbol
click to zoom
PCB Footprints
AT42QT2120-MMHR - Microchip PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - AT42QT2120-MMHR
click to zoom
3D Models
AT42QT2120-MMHR - Microchip - 3D model - Quad Flat No-Lead - AT42QT2120-MMHR
click to zoom

AT42QT2120-MMHR Details

  • Manufacturer Part Number:

    AT42QT2120-MMHR

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    VQFN-20

  • Pin Count:

    20

  • Manufacturer Package Code:

    VQFN-20

  • Country Of Origin:

    South Korea

  • Factory Lead Time:

    7 Weeks

  • Manufacturer:

    Microchip Technology Inc

  • YTEOL:

    14

  • Body Breadth:

    3 mm

  • Body Height:

    0.78 mm

  • Body Length or Diameter:

    3 mm

  • JESD-609 Code:

    e4

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    DIGITAL

  • Output Range:

    0.60-2.60V

  • Output Type:

    DIGITAL VOLTAGE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    LCC20,.12SQ,18

  • Package Shape/Style:

    SQUARE

  • Sensors/Transducers Type:

    CAPACITIVE TOUCH SENSOR

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Min:

    1.8 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

AT42QT2120-MMHR Frequently Asked Questions (FAQs)

  • The recommended PCB layout for the AT42QT2120-MMHR involves placing the sensor on a separate layer from the MCU and other noisy components, using a ground plane to shield the sensor, and keeping the sensor's analog output traces short and away from digital signals.
  • Calibration involves adjusting the sensor's sensitivity and offset to match the specific application requirements. This can be done by applying a known touch stimulus and adjusting the sensor's registers to achieve the desired response.
  • The AT42QT2120-MMHR is rated for operation from -40°C to +85°C, but the optimal operating temperature range is between 0°C to 70°C for best performance and accuracy.
  • To minimize EMI, use a shielded cable for the sensor's analog output, keep the sensor away from sources of EMI, and use a common mode choke or ferrite bead to filter out high-frequency noise.
  • A 10uF ceramic capacitor in parallel with a 100nF ceramic capacitor, placed as close as possible to the sensor's power pins, is recommended for optimal power supply decoupling.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

AT42QT2120-MMHR Overview

Use the download button to access the AT42QT2120-MMHR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AT42Q, or try a keyword search, such as Other Sensors/Transducers

About Microchip

Microchip Technology Inc. is a leading manufacturer of microcontrollers and semiconductor devices for a wide range of applications in the aerospace, automotive, consumer electronics, industrial, and medical industries. Alongside a comprehensive product portfolio, Microchip Technology Inc. also provides easy-to-use development tools that enable engineers to create optimal designs quickly with minimal iterations to reduce risk while lowering total system costs to market. Headquartered in Chandler, Arizona, th
