ATA6562-GBQW0 - Microchip

Description: IC TRANSCEIVER HALF 1/1 8DFN

Download ATA6562-GBQW0 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ATA6562-GBQW0 - Microchip PCB footprint - Small Outline No-lead - Small Outline No-lead - 8-Lead Very Thin Plastic Dual Flat, No Lead Package (Q8B)
click to zoom
3D Models
ATA6562-GBQW0 - Microchip  - 3D model - Small Outline No-lead - 8-Lead Very Thin Plastic Dual Flat, No Lead Package (Q8B)
click to zoom

ATA6562-GBQW0 Details

  • Manufacturer Part Number:

    ATA6562-GBQW0

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Pin Count:

    8

  • Manufacturer Package Code:

    VDFN-8

  • Country Of Origin:

    Taiwan, Thailand

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Date Of Intro:

    2017-08-01

  • Manufacturer:

    Microchip Technology Inc

  • YTEOL:

    20

  • Data Rate:

    5000 Mbps

  • JESD-30 Code:

    S-PDSO-N8

  • Length:

    3 mm

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Number of Transceivers:

    1

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Equivalence Code:

    SOLCC8,.12,25

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1 mm

  • Supply Current-Max:

    85 mA

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    YES

  • Telecom IC Type:

    CAN TRANSCEIVER

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    3 mm

ATA6562-GBQW0 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the ATA6562-GBQW0 is -40°C to +125°C.
  • To configure the ATA6562-GBQW0 for CAN FD mode, set the CANCTRL register to 0x80 and the CANBT1 register to 0x04. Additionally, ensure that the clock frequency is set to 40 MHz or higher.
  • For optimal performance, it is recommended to follow a 4-layer PCB layout with a dedicated ground plane, and to keep the CAN bus lines as short as possible. Also, ensure that the decoupling capacitors are placed close to the device.
  • To troubleshoot CAN bus errors, use a logic analyzer or oscilloscope to monitor the CAN bus signals. Check for errors such as bit stuffing, CRC errors, and acknowledge errors. Also, verify that the CAN bus termination resistors are properly connected.
  • Yes, the ATA6562-GBQW0 is designed to meet the requirements of automotive safety standards such as ISO 26262. However, it is essential to follow the recommended design and testing guidelines to ensure compliance.
