ATA6563-GBQW1-VAO - Microchip

ATA6563-GBQW1-VAO Details

• Manufacturer Part Number:

  ATA6563-GBQW1-VAO

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  VDFN-8

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  7.76

• JESD-30 Code:

  S-PDSO-N8

• Length:

  3 mm

• Number of Functions:

  1

• Number of Terminals:

  8

• Number of Transceivers:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC8,.12,25

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Screening Level:

  AEC-Q100;AEC-Q006

• Seated Height-Max:

  0.9 mm

• Supply Current-Max:

  85 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Telecom IC Type:

  CAN FD TRANSCEIVER

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  3 mm
