ATSAMG55G19B-UUT - Microchip

ATSAMG55G19B-UUT Details

• Manufacturer Part Number:

  ATSAMG55G19B-UUT

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  WLCSP-49

• Pin Count:

  49

• Manufacturer Package Code:

  WLCSP-49

• Country Of Origin:

  Taiwan

• HTS Code:

  8542.31.00.25

• Factory Lead Time:

  36 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  18

• Has ADC:

  YES

• Bit Size:

  32

• Boundary Scan:

  YES

• CPU Family:

  CORTEX-M4F

• Clock Frequency-Max:

  20 MHz

• DAC Channels:

  NO

• DMA Channels:

  YES

• Format:

  FLOATING POINT

• Integrated Cache:

  YES

• JESD-30 Code:

  S-PBGA-B49

• Length:

  2.84 mm

• Low Power Mode:

  YES

• Number of DMA Channels:

  30

• Number of External Interrupts:

  16

• Number of I/O Lines:

  38

• Number of Terminals:

  49

• Number of Timers:

  6

• On Chip Data RAM Width:

  8

• On Chip Program ROM Width:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PWM Channels:

  NO

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA49,7X7,16

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• RAM (bytes):

  180224

• RAM (words):

  90112

• ROM (words):

  524288

• ROM Programmability:

  FLASH

• Seated Height-Max:

  0.533 mm

• Speed:

  120 MHz

• Supply Current-Max:

  0.01 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3.3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Time-Min:

  SECONDS

• Width:

  2.84 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER, RISC
