AUIPS7091GTR - Infineon

Description: Power Switch ICs - Power Distribution Automotive High side 100mohm IPS 75V

Download AUIPS7091GTR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AUIPS7091GTR - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - SOIC8N
click to zoom
3D Models
AUIPS7091GTR - Infineon  - 3D model - Small Outline Packages - SOIC8N
click to zoom

AUIPS7091GTR Details

  • Manufacturer Part Number:

    AUIPS7091GTR

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT, MS-012AA, SOIC-8

  • Country Of Origin:

    Malaysia, Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    7

  • Built-in Protections:

    TRANSIENT; OVER CURRENT; THERMAL

  • Driver Number of Bits:

    1

  • Interface IC Type:

    BUFFER OR INVERTER BASED PERIPHERAL DRIVER

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Length:

    4.9 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Output Current Flow Direction:

    SINK

  • Output Current-Max:

    1.5 A

  • Output Peak Current Limit-Nom:

    5 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Qualification Status:

    Not Qualified

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.75 mm

  • Supply Voltage-Max:

    35 V

  • Supply Voltage-Min:

    6 V

  • Supply Voltage-Nom:

    14 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Turn-off Time:

    45 µs

  • Turn-on Time:

    35 µs

  • Width:

    3.9 mm

AUIPS7091GTR Frequently Asked Questions (FAQs)

  • Infineon recommends a 2-layer or 4-layer PCB with a thermal via array under the device to improve heat dissipation. A minimum of 10 thermal vias with a diameter of 0.3 mm is recommended.
  • To ensure reliable operation in high-temperature environments, it is recommended to derate the device's power dissipation according to the temperature derating curve provided in the datasheet. Additionally, ensure good thermal design and heat sinking to keep the junction temperature below 150°C.
  • Infineon recommends using a ceramic capacitor with a value of 10 μF to 22 μF and a voltage rating of 25 V or higher. The capacitor should be placed as close as possible to the VIN pin to minimize parasitic inductance.
  • To troubleshoot OCP issues, check the input voltage, output current, and sense resistor values. Ensure that the sense resistor is correctly sized and that the OCP threshold is set correctly. Also, verify that the device is not overheating, which can trigger the OCP.
  • Infineon recommends using a ceramic capacitor with a value of 10 μF to 47 μF and a voltage rating of 6.3 V or higher. The capacitor should be placed as close as possible to the VOUT pin to minimize parasitic inductance.
