AUIRF7749L2TR - Infineon

Description: INFINEON - AUIRF7749L2TR - MOSFET, AEC-Q101, N-CH, 60V, DIRECTFET

Download AUIRF7749L2TR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AUIRF7749L2TR - Infineon PCB footprint - Other - Other - DIRECTFET L8 (Large Size Can)
click to zoom
3D Models
AUIRF7749L2TR - Infineon  - 3D model - Other - DIRECTFET L8 (Large Size Can)
click to zoom

AUIRF7749L2TR Details

  • Manufacturer Part Number:

    AUIRF7749L2TR

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    End Of Life

  • Country Of Origin:

    Malaysia, Mexico

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    22 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    1

  • Avalanche Energy Rating (Eas):

    315 mJ

  • Case Connection:

    SOURCE

  • Configuration:

    SINGLE WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    60 V

  • Drain Current-Max (ID):

    36 A

  • Drain-source On Resistance-Max:

    0.0015 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    680 pF

  • JESD-30 Code:

    R-MBCC-N2

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    1

  • Number of Terminals:

    2

  • Operating Mode:

    ENHANCEMENT MODE

  • Operating Temperature-Max:

    175 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    METAL

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Polarity/Channel Type:

    N-CHANNEL

  • Power Dissipation-Max (Abs):

    341 W

  • Pulsed Drain Current-Max (IDM):

    1380 A

  • Reference Standard:

    AEC-Q101

  • Surface Mount:

    YES

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    BOTTOM

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON
