AUIRS20302STR Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  Infineon recommends a 2-layer PCB with a thermal via array under the device to improve heat dissipation. A minimum of 10 thermal vias with a diameter of 0.3 mm is recommended.
• How do I ensure reliable operation in high-temperature environments?
  To ensure reliable operation in high-temperature environments, it is recommended to derate the device's power dissipation according to the temperature derating curve provided in the datasheet. Additionally, ensure good thermal design and heat sinking to keep the junction temperature below 150°C.
• What are the recommended soldering conditions for the AUIRS20302STR?
  Infineon recommends soldering the device using a reflow soldering process with a peak temperature of 260°C for 20-30 seconds. The device is also compatible with wave soldering and hand soldering, but the temperature and time should be adjusted accordingly.
• How do I protect the device from electrostatic discharge (ESD)?
  To protect the device from ESD, handle the device by the body or use an ESD wrist strap or mat. Ensure that the PCB and components are properly grounded, and use ESD-sensitive handling and storage procedures.
• What are the recommended input and output filtering components for the AUIRS20302STR?
  Infineon recommends using a pi-filter (L-C-R) or a common-mode choke at the input and output of the device to filter out electromagnetic interference (EMI) and ensure electromagnetic compatibility (EMC). The specific component values depend on the application and should be determined through simulation and testing.
