AW9523BTQR - AWINIC

Description: 16 MULTI-FUNCTION LED DRIVER AND GPIO CONTROLLER WITH I2C INTERFACE

Download AW9523BTQR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AW9523BTQR - AWINIC PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - TQFN-24L
click to zoom
3D Models
AW9523BTQR - AWINIC  - 3D model - Quad Flat No-Lead - TQFN-24L
click to zoom

AW9523BTQR Details

  • Manufacturer Part Number:

    AW9523BTQR

  • Part Life Cycle Code:

    Contact Manufacturer

  • Package Description:

    TQFN-24

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Shanghai Awinic Technology

AW9523BTQR Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for the AW9523BTQR is -40°C to 85°C, as specified in the datasheet. However, it's essential to note that the device can tolerate a wider temperature range during storage, typically from -55°C to 125°C.
  • To ensure the POR circuitry functions correctly, it's crucial to follow the recommended power-up sequence and voltage ramp rates. The datasheet specifies a minimum voltage ramp rate of 1 ms/V, and the power supply should be stable within 100 ms of power-on. Additionally, the POR circuitry requires a minimum voltage of 1.7 V to function correctly.
  • The maximum current rating for the AW9523BTQR's GPIO pins is 4 mA per pin, as specified in the datasheet. However, it's recommended to limit the current to 2 mA per pin to ensure reliable operation and prevent overheating.
  • To configure the AW9523BTQR's I2C interface for optimal performance, ensure that the I2C clock frequency is within the recommended range of 100 kHz to 400 kHz. Additionally, use pull-up resistors on the SCL and SDA lines, and ensure that the I2C bus is properly terminated to prevent signal reflections.
  • The internal 1.8 V regulator is designed to provide a stable voltage supply for the AW9523BTQR's internal circuitry. To use it, connect the VDD pin to an external power supply, and the internal regulator will generate a stable 1.8 V output on the VDD18 pin. This output can be used to power external components or as a reference voltage.
