AX8052F143-3-TX30 - onsemi

Description: RF System on a Chip - SoC Ult LP 27-1050 MHz RF Microcontroller

Download AX8052F143-3-TX30 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AX8052F143-3-TX30 - onsemi PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - QFN40 7x5, 0.5P
click to zoom
3D Models
AX8052F143-3-TX30 - onsemi  - 3D model - Quad Flat No-Lead - QFN40 7x5, 0.5P
click to zoom

AX8052F143-3-TX30 Details

  • Manufacturer Part Number:

    AX8052F143-3-TX30

  • Brand Name:

    ON Semiconductor

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Manufacturer Package Code:

    485EG

  • Country Of Origin:

    Thailand

  • HTS Code:

    8542.31.00.30

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • JESD-30 Code:

    R-PQCC-N40

  • Length:

    7 mm

  • Moisture Sensitivity Level:

    1

  • Number of Terminals:

    40

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC40,.2X.28,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1 mm

  • Supply Voltage-Max:

    3.6 V

  • Supply Voltage-Min:

    1.8 V

  • Supply Voltage-Nom:

    3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Gold/Palladium (Ni/Au/Pd)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    5 mm

  • uPs/uCs/Peripheral ICs Type:

    RFSOC

AX8052F143-3-TX30 Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the AX8052F143-3-TX30 is 2.2V to 3.6V.
  • To configure the AX8052F143-3-TX30 for low-power mode, set the PWRDN pin high and ensure that the VDDIO pin is connected to a voltage source within the recommended operating range.
  • The AX8052F143-3-TX30 supports a maximum clock frequency of 143 MHz.
  • The AX8052F143-3-TX30 has a built-in watchdog timer that can be enabled by setting the WDTEN bit in the SYSCON register. The watchdog timer can be configured to reset the device after a specified timeout period.
  • The VDDIO pin on the AX8052F143-3-TX30 is used to power the I/O buffers and should be connected to a voltage source within the recommended operating range.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

AX8052F143-3-TX30 Overview

Use the download button to access the AX8052F143-3-TX30 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AX805, or try a keyword search, such as Other uPs/uCs/Peripheral ICs
