AXT440224 - Panasonic

Description: 40 Position Connector Header, Center Strip Contacts Surface Mount Gold

Download AXT440224 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AXT440224 - Panasonic PCB footprint - Other - Other - AXT440224-1
click to zoom

AXT440224 Details

  • Manufacturer Part Number:

    AXT440224

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    Panasonic Electronic Components

  • YTEOL:

    6.98

  • Connector Type:

    FFC/FPC CONNECTOR

  • Contact Finish Mating:

    GOLD OVER NICKEL

  • Contact Finish Termination:

    GOLD OVER NICKEL

  • Contact Gender:

    MALE

  • Contact Material:

    COPPER ALLOY

  • DIN Conformance:

    NO

  • Filter Feature:

    NO

  • IEC Conformance:

    NO

  • JESD-609 Code:

    e4

  • MIL Conformance:

    NO

  • Mating Contact Pitch:

    0.016 inch

  • Mating Information:

    MULTIPLE MATING PARTS AVAILABLE

  • Mixed Contacts:

    NO

  • Mounting Style:

    STRAIGHT

  • Mounting Type:

    BOARD

  • Number Of Connectors:

    ONE

  • Number of Rows Loaded:

    2

  • Option:

    GENERAL PURPOSE

  • Terminal Pitch:

    0.4 mm

  • Termination Type:

    SURFACE MOUNT

  • Total Number of Contacts:

    40

  • UL Flammability Code:

    94V-0

AXT440224 Frequently Asked Questions (FAQs)

  • Panasonic recommends a 4-layer PCB with a solid ground plane and a separate power plane for the input and output. The input and output capacitors should be placed as close as possible to the device pins, and the PCB should be designed to minimize parasitic inductance and capacitance.
  • The AXT440224 has a thermal pad on the bottom of the package, which should be connected to a thermal plane on the PCB. A thermal interface material (TIM) can be used to improve heat transfer between the device and the PCB. Additionally, the PCB should be designed to allow for good airflow around the device.
  • While the datasheet specifies the recommended operating voltage range, it's generally recommended to keep the input voltage deviation within ±10% of the nominal voltage to ensure stable operation and prevent damage to the device.
  • The AXT440224 is rated for operation up to 105°C, but it's recommended to derate the output current and voltage according to the temperature derating curve provided in the datasheet. Additionally, the device should be carefully evaluated for thermal management and reliability in high-temperature applications.
  • Troubleshooting should start with verifying the input voltage, output load, and PCB layout. Check for proper thermal management, and ensure that the device is not operating outside its recommended specifications. Use oscilloscopes and thermal imaging cameras to monitor the device's behavior and identify potential issues.
