AZC015-04F.R7G - Amazing Elec

AZC015-04F.R7G Details

• Manufacturer Part Number:

  AZC015-04F.R7G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN-6

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Amazing Microelectronic Corp

• YTEOL:

  6.81

• Breakdown Voltage-Max:

  9 V

• Breakdown Voltage-Min:

  6 V

• Breakdown Voltage-Nom:

  7.5 V

• Clamping Voltage-Max:

  9 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• Forward Voltage-Max (VF):

  1 V

• JESD-30 Code:

  R-PDSO-N6

• Number of Elements:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  IEC-61000-4-2, 4-4, 4-5

• Rep Pk Reverse Voltage-Max:

  5 V

• Reverse Current-Max:

  5 µA

• Reverse Test Voltage:

  5 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL
