B78419A2289A003 - TDK

B78419A2289A003 Details

• Manufacturer Part Number:

  B78419A2289A003

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  32 Weeks

• Manufacturer:

  TDK Corporation

• YTEOL:

  9

• Approvals:

  AEC-Q200; IEC; CUL; UL

• Height:

  13.95 mm

• Length:

  12.6 mm

• Load Resistance:

  2.1 Ω

• Mounting Feature:

  SURFACE MOUNT

• Operating Frequency-Max:

  250 kHz

• Operating Frequency-Min:

  50 kHz

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR, BLISTER, 13 INCH

• Peak Primary Current:

  30 A

• Primary Type:

  WOUND PRIMARY

• Secondary Inductance:

  3000 µH

• Surface Mount:

  YES

• Transformer Type:

  CURRENT SENSE TRANSFORMER

• Turns Ratio (Np:Ns):

  1:70

• Width:

  11.3 mm
