B82724V2103U040 - TDK

B82724V2103U040 Details

• Manufacturer Part Number:

  B82724V2103U040

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• Country Of Origin:

  India

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  TDK Corporation

• YTEOL:

  6

• Construction:

  Rectangular

• Core Material:

  FERRITE

• DC Resistance:

  0.0092 Ω

• Inductance-Nom (L):

  3300 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Diameter:

  1.25 mm

• Lead Length:

  4.5 mm

• Number of Functions:

  2

• Number of Terminals:

  4

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  30 mm

• Package Length:

  33 mm

• Package Style:

  Radial

• Package Width:

  23 mm

• Packing Method:

  Bulk

• Rated Current-Max:

  10 A

• Reference Standard:

  EN; VDE

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Special Feature:

  INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.01 MHz

• Tolerance:

  50%
