B82733F2192B001 - TDK

B82733F2192B001 Details

• Manufacturer Part Number:

  B82733F2192B001

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  TDK Corporation

• YTEOL:

  6.9

• Construction:

  Rectangular

• Core Material:

  FERRITE

• DC Resistance:

  0.279 Ω

• Inductance-Nom (L):

  15000 µH

• Inductor Application:

  COMMON MODE CHOKE

• Inductor Type:

  COMMON MODE CHOKE

• JESD-609 Code:

  e3

• Lead Length:

  3.5 mm

• Number of Functions:

  2

• Number of Terminals:

  4

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  14 mm

• Package Length:

  26.5 mm

• Package Style:

  PCB Mount

• Package Width:

  24.8 mm

• Packing Method:

  Tray

• Rated Current-Max:

  1.9 A

• Reference Standard:

  EN; IEC; UL; VDE

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Special Feature:

  INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Terminal Placement:

  DUAL IN-LINE

• Terminal Shape:

  FLAT

• Test Frequency:

  0.01 MHz

• Tolerance:

  50%
