BA30E00WHFP-TR - ROHM Semiconductor

BA30E00WHFP-TR Details

• Manufacturer Part Number:

  BA30E00WHFP-TR

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  MODULE

• Pin Count:

  7

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  0

• Adjustability:

  FIXED/ADJUSTABLE

• Dropout Voltage1-Max:

  0.6 V

• Dropout Voltage1-Nom:

  0.3 V

• Dropout Voltage2-Max:

  0.6 V

• Input Voltage Absolute-Max:

  18 V

• JESD-30 Code:

  R-PSSO-G7

• Length:

  9.395 mm

• Line Regulation-Max:

  0.09%

• Line Regulation-Max (%/V):

  0.31

• Load Regulation-Max:

  0.09%

• Load Regulation-Max(%):

  11.25%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  7

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -25 °C

• Output Current1-Max:

  0.6 A

• Output Current2-Max:

  0.6 A

• Output Voltage1-Max:

  3.366 V

• Output Voltage1-Min:

  3.234 V

• Output Voltage1-Nom:

  3.3 V

• Output Voltage2-Max:

  3.3 V

• Output Voltage2-Min:

  0.8 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SMSIP7H,.4,50TB

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED/ADJUSTABLE POSITIVE MULTIPLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  2.005 mm

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  SINGLE

• Voltage Tolerance-Max:

  2%

• Width:

  8 mm
