BAP64Q,125 - NXP

BAP64Q,125 Details

• Manufacturer Part Number:

  BAP64Q,125

• Source Url Status Check Date:

  2013-06-14 00:00:00

• Brand Name:

  NXP Semiconductor

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TSOP

• Package Description:

  SOT-753, SC-74A, 5 PIN

• Pin Count:

  5

• Manufacturer Package Code:

  SOT753

• Country Of Origin:

  Malaysia

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Application:

  ATTENUATOR

• Breakdown Voltage-Min:

  100 V

• Configuration:

  COMPLEX

• Diode Capacitance-Max:

  0.35 pF

• Diode Capacitance-Nom:

  0.23 pF

• Diode Element Material:

  SILICON

• Diode Forward Resistance-Max:

  1.35 Ω

• Diode Res Test Current:

  100 mA

• Diode Res Test Frequency:

  100 MHz

• Diode Type:

  PIN DIODE

• Frequency Band:

  S BAND

• JESD-30 Code:

  R-PDSO-G5

• JESD-609 Code:

  e3

• Minority Carrier Lifetime-Nom:

  1.55 µs

• Moisture Sensitivity Level:

  1

• Number of Elements:

  4

• Number of Terminals:

  5

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Power Dissipation-Max:

  0.125 W

• Reference Standard:

  IEC-60134

• Reverse Test Voltage:

  100 V

• Surface Mount:

  YES

• Technology:

  POSITIVE-INTRINSIC-NEGATIVE

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30
