BAS70-04 - Diodes Incorporated

BAS70-04 Details

• Manufacturer Part Number:

  BAS70-04

• Pbfree Code:

  No

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOT-23

• Package Description:

  SOT-23, 3 PIN

• Pin Count:

  3

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.70

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  0

• Configuration:

  SERIES CONNECTED, CENTER TAP, 2 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.41 V

• JESD-30 Code:

  R-PDSO-G3

• JESD-609 Code:

  e0

• Non-rep Pk Forward Current-Max:

  0.1 A

• Number of Elements:

  2

• Number of Terminals:

  3

• Output Current-Max:

  0.07 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Power Dissipation-Max:

  0.33 W

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  70 V

• Surface Mount:

  YES

• Technology:

  SCHOTTKY

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
