BCL-C18LMYG footprint, schematic symbol and 3D model by Honda Connectors

Symbol

click to zoom

PCB Footprints

BCL-C18LMYG - Honda Connectors PCB footprint - Other - Other - BCL-C18LMYG-4

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for BCL-C18LMYG
Part Number BCL-C18LMYG
Manufacturer Honda Connectors
Pin Count 19
Part Category Connector
Package Category Other
Footprint Name Other - BCL-C18LMYG-4
Released Date Sep 11, 2022
Last Modified Date Mar 7, 2023 4:10 PM UTC
Pinout / Pin List Click Here (Member Only)

BCL-C18LMYG Details

Manufacturer Part Number:
BCL-C18LMYG
Rohs Code:
Yes
Part Life Cycle Code:
Contact Manufacturer
ECCN Code:
EAR99
HTS Code:
8536.69.40.30
Manufacturer:
Honda Tsushin Kogyo Co Ltd
Additional Feature:
PANEL MOUNTABLE
Connector Type:
TELECOM AND DATACOM CONNECTOR
Contact Finish Mating:
GOLD
Contact Finish Termination:
Gold (Au)
Contact Gender:
MALE
DIN Conformance:
NO
Empty Shell:
NO
Filter Feature:
NO
IEC Conformance:
NO
JESD-609 Code:
e4
MIL Conformance:
NO
Mating Information:
MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts:
YES
Mounting Style:
RIGHT ANGLE
Mounting Type:
BOARD AND PANEL
Option:
WATERPROOF
Shell Material:
LIQUID CRYSTAL POLYMER
Termination Type:
SURFACE MOUNT
Total Number of Contacts:
18
UL Flammability Code:
94V-0

BCL-C18LMYG Frequently Asked Questions (FAQs)

The recommended storage condition for BCL-C18LMYG is in a cool, dry place away from direct sunlight, with a temperature range of 10°C to 30°C and humidity below 60%.
Yes, BCL-C18LMYG is suitable for outdoor use, but it's essential to ensure proper sealing and protection from environmental factors such as moisture, dust, and extreme temperatures.
The maximum operating temperature range for BCL-C18LMYG is -40°C to 85°C, but it's recommended to operate within the specified temperature range for optimal performance and reliability.
Yes, BCL-C18LMYG is compatible with lead-free soldering, but it's essential to follow the recommended soldering profile and temperature to avoid damaging the component.
The typical lead time for BCL-C18LMYG varies depending on the supplier and the quantity required. It's recommended to check with the supplier or distributor for the most up-to-date lead time information.

Trust Checks

Community Provided

System Verified

Community Approved

BCL-C18LMYG Overview

Use the download button to access the BCL-C18LMYG schematic symbol and PCB footprint.

To find more CAD model downloads similar to this part, try a partial part number search, like BCL-C, or try a keyword search, such as Telecom and Datacom Connectors
