BCM48BH120T120B00 - VICOR

BCM48BH120T120B00 Details

• Manufacturer Part Number:

  BCM48BH120T120B00

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-28

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Factory Lead Time:

  28 Weeks

• Manufacturer:

  Vicor Corporation

• YTEOL:

  6

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CTUVUS, CURUS, UKCA

• Efficiency (Main Output):

  95%

• Input Voltage-Max:

  55 V

• Input Voltage-Min:

  38 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XQMA-J28

• Length:

  22 mm

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  28

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  10 A

• Output Voltage-Max:

  14 V

• Output Voltage-Min:

  8.5 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  QMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  UNDER VOLTAGE, OVER VOLTAGE, OVER CURRENT, SHORT CIRCUIT, THERMAL

• Ripple Voltage (Main Out):

  0.1414 Vrms

• Seated Height-Max:

  6.98 mm

• Supply Voltage-Max (Vsup):

  55 V

• Supply Voltage-Min (Vsup):

  38 V

• Supply Voltage-Nom (Vsup):

  48 V

• Surface Mount:

  YES

• Technology:

  HYBRID

• Temperature Grade:

  AUTOMOTIVE

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  J BEND

• Terminal Position:

  QUAD

• Total Power Output-Max:

  120 W

• Trim/Adjustable Output:

  YES

• Width:

  16.5 mm
