BCM6123TD1E2663T00 - VICOR

BCM6123TD1E2663T00 Details

• Manufacturer Part Number:

  BCM6123TD1E2663T00

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  28 Weeks

• Manufacturer:

  Vicor Corporation

• YTEOL:

  9.2

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CTUVUS, CURUS, UKCA

• Efficiency (Main Output):

  97.3%

• Input Voltage-Max:

  410 V

• Input Voltage-Min:

  260 V

• Input Voltage-Nom:

  384 V

• JESD-30 Code:

  R-XDMA-T24

• Length:

  61 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  24

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  62.5 A

• Output Voltage-Max:

  25.6 V

• Output Voltage-Min:

  16.3 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL

• Ripple Voltage (Main Out):

  0.053025 Vrms

• Seated Height-Max:

  7.31 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1500 W

• Trim/Adjustable Output:

  NO

• Width:

  25.14 mm
