A 4-layer PCB with a solid ground plane and thermal vias is recommended. The device should be placed near a thermal interface material (TIM) and a heat sink for optimal heat dissipation.
A soft-start circuit can be implemented to limit the inrush current during start-up. A voltage supervisor can be used to ensure the device is fully powered on before enabling the output. A power-on reset (POR) circuit can also be used to ensure a clean start-up and shutdown sequence.
The output voltage ripple and noise are affected by the output capacitor (Cout), the inductor (L), and the switching frequency (fsw). A larger Cout and a higher fsw can reduce the output voltage ripple, while a larger L can reduce the output voltage noise.
Optimize the design by selecting the right components, such as low-ESR capacitors and a low-RDS(on) MOSFET. Minimize the PCB trace resistance and inductance, and use a high-frequency switching frequency to reduce the energy losses. Additionally, consider using a synchronous rectification scheme to reduce the power losses.
Key considerations for EMI and EMC compliance include using a shielded enclosure, minimizing the PCB trace length and loop area, using a common-mode choke, and adding EMI filters to the input and output lines. Additionally, ensure that the device is placed away from sensitive circuits and antennas.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
BCM6123TD1E2663T01 Overview
Use the download button to access the BCM6123TD1E2663T01 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BCM61,
or try a keyword search, such as Power Supply Modules
