BCM6123TD1E5117T01 - VICOR

BCM6123TD1E5117T01 Details

• Manufacturer Part Number:

  BCM6123TD1E5117T01

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  28 Weeks

• Manufacturer:

  Vicor Corporation

• YTEOL:

  9

• Additional Feature:

  47.5V SECONDARY INPUT AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, EN, UKCA, UL

• Efficiency (Main Output):

  97.7%

• Input Voltage-Max:

  410 V

• Input Voltage-Min:

  260 V

• Input Voltage-Nom:

  380 V

• JESD-30 Code:

  R-XDMA-T9

• JESD-609 Code:

  e4

• Length:

  63.34 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  16.9 A

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE, UNDER VOLTAGE,SHORT CIRCUIT,THERMAL

• Ripple Voltage (Main Out):

  0.9898 Vrms

• Seated Height-Max:

  7.31 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.38 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1250 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.33 s

• Width:

  22.8 mm
