BCQ1300-48S12B-4L - Advanced Energy

BCQ1300-48S12B-4L Details

• Manufacturer Part Number:

  BCQ1300-48S12B-4L

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Advanced Energy Industries Inc

• YTEOL:

  8

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  TUV, CE, UL, CUL

• Efficiency (Main Output):

  97.7%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  40 V

• JESD-30 Code:

  R-XDMA-P7

• Length:

  58.4 mm

• Load Regulation-Max:

  3.0464%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  7

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  90 A

• Output Voltage-Max:

  14.5 V

• Output Voltage-Min:

  9.6 V

• Output Voltage-Nom:

  13.13 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  255

• Protections:

  THERMAL; OUTPUT OVER VOLTAGE

• Screening Level:

  UL 62368-1

• Seated Height-Max:

  15 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  7

• Total Power Output-Max:

  1300 W

• Trim/Adjustable Output:

  NO

• Width:

  36.8 mm
