BCR08AS-12AT14#B11 - Renesas Electronics

BCR08AS-12AT14#B11 Details

• Manufacturer Part Number:

  BCR08AS-12AT14#B11

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  UPAK

• Package Description:

  SOT-89, 3 PIN

• Pin Count:

  4

• Manufacturer Package Code:

  PLZZ0004CA

• ECCN Code:

  EAR99

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Case Connection:

  MAIN TERMINAL 2

• Configuration:

  SINGLE

• Critical Rate of Rise of Commutation Voltage-Min:

  0.5 V/us

• DC Gate Trigger Current-Max:

  5 mA

• DC Gate Trigger Voltage-Max:

  2 V

• JESD-30 Code:

  R-PSSO-F3

• Number of Elements:

  1

• Number of Terminals:

  3

• On-State Voltage-Max:

  2 V

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  Embossed Tape

• RMS On-state Current-Max:

  0.8 A

• Repetitive Peak Off-state Leakage Current-Max:

  2000 µA

• Repetitive Peak Off-state Voltage:

  600 V

• Surface Mount:

  YES

• Terminal Form:

  FLAT

• Terminal Position:

  SINGLE

• Trigger Device Type:

  TRIAC
