BCR16RM-12LB#B00 - Renesas Electronics

BCR16RM-12LB#B00 Details

• Manufacturer Part Number:

  BCR16RM-12LB#B00

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TO-3PFM

• Pin Count:

  3

• Manufacturer Package Code:

  PRSS0003ZA

• ECCN Code:

  EAR99

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Critical Rate of Rise of Commutation Voltage-Min:

  1 V/us

• DC Gate Trigger Current-Max:

  30 mA

• DC Gate Trigger Voltage-Max:

  1.5 V

• JEDEC-95 Code:

  TO-3

• JESD-30 Code:

  R-PSFM-T3

• Number of Elements:

  1

• Number of Terminals:

  3

• On-State Voltage-Max:

  1.5 V

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Packing Method:

  TUBE

• RMS On-state Current-Max:

  16 A

• Reference Standard:

  UL RECOGNIZED

• Repetitive Peak Off-state Leakage Current-Max:

  5000 µA

• Repetitive Peak Off-state Voltage:

  800 V

• Surface Mount:

  NO

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Trigger Device Type:

  TRIAC
